Equipped with a 800W/RMS digipro® digital power amp including switch mode supply, this unit provides a high sound pressure level of up to 131dB.
Furthermore there is a powercon in and out for mains connection.
Made of durable multiplex housing covered in robust black textured lacquer, the high-quality housing provides six carrying handles, an M20 pole mount, and bushings on the rear panel that accept casters.
Read More
TECHNOLOGIES
Technical Data
Speaker Type
Active Bassreflex Subwoofer
Acoustical data
Frequency Response [+/- 3dB]
40 - 150 Hz
Max SPL
131 dB
Directivity
Omnidirectional
LF
12 "
Voice Coil LF
3 "
Amplifier
Amp Technology
Digipro®
Amp Class
Class D
LF Amp
800 W RMS
Cooling
Convection
Processor
Controller
Digital + Analog (Stereo)
Phase
0, 180 °
Limiter
RMS, Peak, Thermal
Delay Option
NO
Crossover Frequency LF-MF
90, 120 Hz
LF-Xover out slope
24 dB/Octave
Mechanics
Housing
Multiplex plywood
Housing Design
Rectangular
Handles
1x on top
Pole Mount
2x M20
Accessory
Dust Cover
Width
360 mm (20.8 in)
Height
520 mm (14.4 in)
Depth
500 mm (20 in)
Weight
23 kg (50.71 lbs)
Notes: The data are not binding; dBTechnologies reserves the right to modify the data at any time and without previous notice.
