Multifunctional HousingA multifunctional housing offers many placement options, for instance as a floor monitor, satellite speaker in combination with subwoofers or as a fullrange system on pole mounts.
Technical Data
Speaker Type
2-Way Active Speaker
Acoustical data
Frequency Response [-10dB]
100 - 16.000 Hz
Max SPL
101 dB
Type HF
Tweeter
LF
5 “
Amplifier
Power PRG
100 W
Cooling
Convection
Processor
Controller
Analog
Limiter
Soft Clip
Input
Signal Input
1x XLR
1x 6.3mm phone jack
1x RCA cinch
Microphone Input
YES
Signal Output
1x XLR
1x 6.3mm phone jack
1x RCA cinch
Power Socket
VDE
Voltage Range
240 V
Mechanics
Housing
Polyporpylen PP
Width
170 mm (6.8 in)
Height
270 mm (10.8 in)
Depth
185 mm (7.4 in)
Weight
3.5 kg (7.72 lbs)
Notes: The data are not binding; dBTechnologies reserves the right to modify the data at any time and without previous notice.
