The S118 is a powerful, active 18“ subwoofer housed in a bassreflex enclosure.
Designed specifically to provide low-frequency support for high performance S115 fullrange speakers, it packs a mighty low-ranging bass punch.
S118 and S115 enclosures have the same width so they are easily stacked to set up professional-grade PA systems.
Read More
TECHNOLOGIES
Digipro® G2System of digital amplification engineered by dBTechnologies. Based on the previous Digipro project, the newest G2 versions' efficiency has been improved by cutting down on consumption and heating. The introduction of a 'new avant-garde' component, a better s/n relation and a lighter weight, confer a superior dynamism to the new Digipro G2 digital speakers.
Technical Data
Speaker Type
Active Bassreflex Subwoofer
Acoustical data
Frequency Response [-10dB]
38 - 110 Hz
Max SPL
134 dB
Directivity
omnidirectional
LF
18 "
Voice Coil LF
4 "
Amplifier
Amp Technology
Digipro® G2
Amp Class
Class D
PRG Power
1400 W
Processor
Controller
Analog/Digital
Limiter
Peak, RMS, Thermal
Crossover Frequency MF-HF
80-100 Hz (Switchable)
LF-Xover out slope
24 dB/Octave
Input
Signal Input
XLR
Input Sensitivity [dBu]
-3dBu
Signal Output
1x XLR X-Over Out/ Link Out
Mechanics
Housing
Multiplex with H.E.T coating, reinforced
Width
509 mm (20.36 in)
Height
815 mm (32.6 in)
Depth
533 mm (21.32 in)
Weight
38 kg (83.78 lbs)
Notes: The data are not binding; dBTechnologies reserves the right to modify the data at any time and without previous notice.
