To complete the extension of low frequencies, the IS series offers two passive subwoofers, each equipped with a single 8'' or 12'' woofer.
The compact dimensions and standard design that characterize the two complements guarantee discreet, non-intrusive applications with high durability.
IS12S-WP retains the minimal design of the entire series, with the possibility of customizing the color finish of the white version by yourself.
Read More
TECHNOLOGIES
EASE FocusEASE Focus makes configuring a DVA or VIO system so much easier as this software simulates the system in the virtual realm. It can depict several audience target zones at the same time to map out more intricate venues including different coverage areas such as arenas, bleachers, and balconies. Color 2D graphics provide an easily understandable view of throw patterns and sound pressure levels so you can configure the array for the best possible results. It also offers you easy access to key rigging parameters such as the height of the rigging frame, the choice of pick points, the array’s bend, total weight, and system preset selections.
IP55 RatingThe product is resistant to dust and low-pressure water jets. Specifically, IP55 Rating offers limited protection against dust ingress and can withstand water jets from any direction without compromising functionality. This rating is commonly used for devices intended for both indoor and outdoor use.
White version availableThis product is available for purchase in black or white.
Product code: 1030401280
Technical Data
Speaker Type
Passive Subwoofer
Acoustical data
RMS Power
250 W
Peak Power
1000 W
Frequency Response [-6 dB]
40 Hz - custom LPF
Impedance
8 Ohm
Sensitivity 1W@m
97.5 dB
Max SPL
127.5 dB
LF
1x 12", 2.5" v.c.
Input
Connections
Screw terminal block (IN+ | IN- | OUT+ | OUT-)
Mechanics
Housing
Plywood, polyurea coating
Rigging points
16x M8 pickup point
IP rating
IP 55
Width
335 mm (13.2 in)
Height
624 mm (24.6 in)
Depth
400 mm (15.7 in)
Weight
15 kg (33 lbs)
Notes: The data are not binding; dBTechnologies reserves the right to modify the data at any time and without previous notice.
Filename:
Category:
Filetype:
Size:
Language:
Release:
DWG_IS12S
Drawing
DWG
0,52 MB
English
2021-05-19
Quick-Start_IS8S-WP-IS12S-WP_Rev1.0
Manual
PDF
1,58 MB
English
2024-11-13
GLL_IS12S_v1.1
GLL
ZIP
5,26 MB
English
2022-01-18
PresetsInstaller_1.2_osx
Software
ZIP
19,68 MB
English
2024-07-31
PresetsInstaller_1.2_win
Software
ZIP
19,69 MB
English
2024-08-01
SP-IS
Electronics
