From the dBTecnologies experience in the world of sound reinforcement, the first high-performance point source for high-profile installations is born.
Combining excellent acoustic performance with the versatility guaranteed by dedicated accessories for flyable or pole configurations, IS210T is a solution designed for sound reinforcement in medium and large environments such as arenas, performing arts center, houses of worship, multifunctional venues, and clubs.
The symmetrical configuration with two 10'' woofers makes the top performing both in indoor and outdoor acoustic contexts; the IP55 certification ensures high resistance to different weather conditions and increase the system durability. IS210T is available in white and black, with the possibility of customizing the color finish of the white version by yourself.
Read More
TECHNOLOGIES
EASE FocusEASE Focus makes configuring a DVA or VIO system so much easier as this software simulates the system in the virtual realm. It can depict several audience target zones at the same time to map out more intricate venues including different coverage areas such as arenas, bleachers, and balconies. Color 2D graphics provide an easily understandable view of throw patterns and sound pressure levels so you can configure the array for the best possible results. It also offers you easy access to key rigging parameters such as the height of the rigging frame, the choice of pick points, the array’s bend, total weight, and system preset selections.
Rotatable HornSpecially designed, rotatable high-frequency horns provide very clean and constant directivity. By rotating the horn, the directivity of high frequencies can be adjusted, depending on the cabinet being assembled horizontally or vertically. A great and professional feature for fixed installation purposes or when a multifunctional speaker is used as stage monitor.
IP55 RatingThe product is resistant to dust and low-pressure water jets. Specifically, IP55 Rating offers limited protection against dust ingress and can withstand water jets from any direction without compromising functionality. This rating is commonly used for devices intended for both indoor and outdoor use.
Product code: 1030401190
Technical Data
Speaker Type
2-way Passive Fullrange Speaker
Acoustical data
RMS Power
400W (LF: 300W | HF: 100W)
Peak Power
1600W (LF: 1200W | HF: 400W)
Usable bandwidth [-10 dB]
56 Hz - 20,000 Hz
Frequency Response [-6 dB]
60 Hz - 17,800 Hz
Impedance
8 Ohm
Max SPL
133 dB
HF
1x 1.4" (exit), 2.4" v.c.
LF
2x 10", 2.5" v.c.
Dispersion
90x40° [rotatable horn]
X-Over Frequency
840 Hz (internal X-Over)
Input
Connections
Screw terminal block (LF+ | LF- | HF+ | HF-)
Mechanics
Housing
Plywood, water-painted coating
Rigging points
flyable with bracket
IP rating
IP 55
Width
300 mm (11.81 in)
Height
780 mm (30.71 in)
Depth
430 mm (16.93 in)
Weight
28.7 Kg (63 lbs)
Notes: The data are not binding; dBTechnologies reserves the right to modify the data at any time and without previous notice.
