With this new VIO W15T the perfect touring wedge goes VIO. It is a powerful and versatile stage monitor able to keep up with our premium line array series.
With this new VIO W15T the perfect touring wedge goes VIO. It is a powerful and versatile stage monitor able to keep up with our premium line array series.
VIO W15T takes advantage of a coaxial design and is equipped with a neodymium coaxial component with a 15" woofer and a 3" driver.
The design of the horn allows a very precise dispersion pattern (60° horizontal and 80° vertical) which can be easily reversed by rotating the horn, adapting the wedge to the application needed. VIO W15T is a self powered box equipped with top notch class-D Digipro G4 amplifier delivering 1600W RMS. This is the same amp module used in our premium sound reinforcement systems. VIO W15T is able to deliver up to 137 dB SPL while offering a great feedback rejection. Moreover, the sound processing takes advantage of FIR filters in order to reproduce a very flat frequency and phase response resulting in the most faithful audio performance.
The PFC power factor corrector allows for the utmost reliability at any input voltage. A 380v resistant power supply makes the wedge shock resistant. And a real time impedance control allows for a real time check of transducers' health.  Aurora Net software continuously runs this test, but you can check the wedge at any time, simply by pressing this button on board.
The same software also allows for DSP management such as delay, eq and levels. A hi-brightness LED bulb on the front of the enclosure, contributes to help the user to recognize, identify and match each cabinet with its software alias. As a default, the preamplifier is equipped with a RDNet card, and it is ready for upgrade to Dante card.
The preamp module is flush mounted in the side panel, so that no connector are visible. And this will definitely looks nice on a stage also thanks to the clever surrounding design of the metal grille. Furthermore, this allows for sidestacking of two wedges with no gap.
When used vertically, e.g. for drumfill applications. the preamp is completely protected from the rain.
A great versatility is granted by the addition of a multifunctional bracket, enabling the wedge for pole mounting and other kind of fixed applications.
Technical Data
Speaker Type
2-Way Active Coaxial Stage Monitor
Acoustical data
Usable Bandwith [- 10 dB]
49 - 17,500 Hz
Frequency Response [- 6 dB]
55 - 16,000 Hz
Max SPL
137.5 dB
HF
1x 1.3" - 3" v.c. Neodymium
LF
1x 15" - 3" v.c. Neodymium
Directivity (HxV)
80° x 60° [rotatable]
Amplifier
Amplifier
1600 W RMS Class D Digipro® G4
Cooling
Convection + internal fan
Power Supply
Full-range SMPS with PFC (100V~-240V~, 50-60Hz)
Processor
Controller
DSP 32 bit
Converter AD/DA
24 bit/96 kHz
Limiter
Dual Active Peak, RMS, Thermal
Processing (filters)
Linear Phase FIR Filters
Input
Signal Input
1x XLR female, 1 x USB (Data Service)
Signal Output
1xXLR male
Expansion Card
RDNet Card (1x RJ45 IN 1x RJ45 Link)
Dante Card [Optional]
Power Socket
1x PowerCON TRUE1 In
1xPowerCON TRUE1 Out
Controls
1x switch Flat - service/user
1x switch System test
1x led ON
1x led STATUS
1x led SIGNAL
1x led LIMITER
1x LED TEST
1x frontal ID led
Special Features
Frontal LED Identification System
380V Resistant SMPS
Opto-isolated floating pre-amp
System Test (transducers diagnostics)
Mechanics
Housing
Wooden cabinet, Polyurea painting
Handles
1 + 2 recessions per side
Width
650 mm (25.59 in)
Height
360 mm (14.17 in)
Depth
490 mm (19.29 in)
Weight
29 kg (63.9 lbs)
Notes: The data are not binding; dBTechnologies reserves the right to modify the data at any time and without previous notice.
Features
  • Active 2-way Coaxial Stage monitor
  • 1600W RMS Class-D amplifier
  • Rotatable horn
  • FULL RANGE SMPS WITH PFC
  • ADVANCED DSP FEATURING LINEAR PHASE FIR FILTERS
  • MODULAR SLOT FOR NETWORK AND DIGITAL AUDIO EXPANSION CARDS (RDNET CARD INSTALLED)
  • NFC™ + FRONT LED IDENTIFICATION SYSTEM
  • SYSTEM TEST FOR QUICK TRANSDUCERS DIAGNOSTICS
  • Exclusive front-rear grille design
/images/299/5504/70x70/nocrop/q-100/align-4/380V-SMPS-icon.png
380V resistant SMPS
The final amplifiers will be switched off in case of an undesired strike of 380V current, saving them from any damage. The auxiliary power supply - 380V tolerant - determines a safe range of operability for the man power supply.
/images/299/4949/70x70/nocrop/q-100/align-4/Logo-Aurora-no-scritta.png
Aurora Net
This product is fully-compatible with Aurora Net software
/images/299/796/70x70/nocrop/q-100/align-4/ICONES_COAXIAL.png
Coaxial Speaker
These newly developed coaxial speakers deliver an extraordinary sound quality that defies the compact design of their housings.
Engineered for precise directivity and uniform throw patterns, they provide the same satisfying audio experience from every listening position, with far greater resistance to Feedback.
/images/299/4051/70x70/nocrop/q-100/align-4/digipro-G4-dbtechnologies.png
DIGIPRO® G4
The latest System of digital amplification engineered by dBTechnologies.


/images/299/5508/70x70/nocrop/q-100/align-4/ex-card-slot-icon.png
Expansion Card Slot
The preamplifier comes with a RDNet card installed. The user will be able to upgrade the system by replacing the RDNet card with an Audinate™ Dante™ card for audio over Ethernet and remote control on a single cable solution - sold separately.
/images/299/3731/70x70/nocrop/q-100/align-4/FIR-filters-icon.png
Linear Phase FIR Filters
A low-latency sound processing featuring Linear Phase FIR filters allows VIO cabinets to deliver an extremely coherent audio performance, standing out for its intelligibility and clarity from every listening position. This is also achieved by making the phase response as linear as possible, avoiding any distortion.
/images/299/5507/70x70/nocrop/q-100/align-4/Opto-isolated-icon.png
Opto-isolated Preamp
The floating audio input design grants a digital optical isolation between earth ground from the mains and the audio ground flowing into the Preamplifier board.
This galvanic isolation greatly improves resistance to interferences and any unwanted buzzing and noises.
/images/299/818/70x70/nocrop/q-100/align-4/ICONES_PFC.png
PFC (Power Factor Corrector)
The Power Factor Corrector greatly improves the efficiency of the system. Performances of the amplifier are very stable and consistent, regardless of the quality of the mains. This also grants a worldwide compatibility of the power supply - from 90V to 265V 50/60Hz - and limits power consumption.
/images/299/816/70x70/nocrop/q-100/align-4/ICONES_RD_Net.png
RDNet
Digital net for bi-directional control of connected devices.
The acronym RDNet originates from the development, on behalf of RCF and dBTechnologies, of a universal network which allows adjustments in real time and supervision of all the connected systems, using cables based on ethernet cat 5 wires.
With the specific software and the interfaces control 2 and control 8, a complete command of the acoustic system will be possible allowing real time supervision on each electrical component of the various speakers.

RDNet allows you to

Monitor levels, limiters, and temperatures
Select system presets
Configure setups off-line
Mute units
Group modules and assigning group EQ, delay and phase
Test individual components
Automatically address system components
Tap into LAN and USB interfaces
Extend the network via wireless LAN access points.
/images/299/812/70x70/nocrop/q-100/align-4/ICON_ROTABLE_CD_HORN.png
Rotatable Horn
Specially designed, rotatable high-frequency horns provide very clean and constant directivity.
By rotating the horn, the directivity of high frequencies can be adjusted, depending on the cabinet being assembled horizontally or vertically.
A great and professional feature for fixed installation purposes or when a multifunctional speaker is used as stage monitor.
/images/299/5503/70x70/nocrop/q-100/align-4/System-test-icon.png
System Test
A built-in measurement system can read the transducers impedance in real time and provide an instant feedback on the health of your system.
This controls is performed constantly or it can be forced by the user at any time, remotely or from the amplifier panel.
/images/299/5509/70x70/nocrop/q-100/align-4/USB-icon.png
USB Data Port
Thanks to this universal data port, the user will be able to perform firmware upgrades
