IS6T-WP

Point Sources
Point Sources
208 mm 274.5 mm 195 mm

PASSIVE 2-WAY COAXIAL SPEAKER

MAX SPL 119 dB

FREQ RESPONSE [-6dB]: 85 Hz - 20,000 Hz

HF: 1x 0.75", 1" v.c. NEODYMIUM

LF: 1x 6.5", 1.5" v.c. COAXIAL WOOFER

IP55 CERTIFIED

BRACKET INCLUDED

WEIGHT: 4.8 Kg (10.6 lbs)

Sales & Rental Network

IS6T-WP è il diffusore coassiale compatto e resistente per installazioni indoor e outdoor.

Dotato di un componente coassiale da 6.5”, è un cabinet compatto ad alta versatilità, progettato essenzialmente per la musica di sottofondo.

Semplice e resistente, è una soluzione ottimale per la sonorizzazione indoor e outdoor attraverso un’installazione veloce garantita dalla staffa inclusa, punti di montaggio invisibili e una certificazione IP55. Ulteriore versatilità di connessione è supportata dai diversi accessori dedicati.

IS6T-WP conserva il design uniforme e minimale della serie, con la possibilità di personalizzare autonomamente la finitura cromatica della versione in bianco sulla base delle esigenze estetiche dell’installazione.

Scopri di più

TECNOLOGIE

Coaxial Speaker
Coaxial SpeakerThese coaxial speakers deliver an extraordinary sound quality that defies the compact design of their housings. Engineered for precise directivity and uniform throw patterns, they provide the same satisfying audio experience from every listening position, with far greater resistance to Feedback.
EASE Focus
EASE FocusEASE Focus makes configuring a DVA or VIO system so much easier as this software simulates the system in the virtual realm. It can depict several audience target zones at the same time to map out more intricate venues including different coverage areas such as arenas, bleachers, and balconies. Color 2D graphics provide an easily understandable view of throw patterns and sound pressure levels so you can configure the array for the best possible results. It also offers you easy access to key rigging parameters such as the height of the rigging frame, the choice of pick points, the array’s bend, total weight, and system preset selections.
IP55 Rating
IP55 RatingThe product is resistant to dust and low-pressure water jets. Specifically, IP55 Rating offers limited protection against dust ingress and can withstand water jets from any direction without compromising functionality. This rating is commonly used for devices intended for both indoor and outdoor use.
White version available
White version availableThis product is available for purchase in black or white.
Codice prodotto: 1030401230
Dati tecnici
Speaker Type
Passive 2-way Coaxial Speaker
Dati acustici
RMS Power
100 W
Peak Power
400 W
Frequency Response [-6 dB]
85 Hz - 20,000 Hz
Impedance
8 Ohm
Sensitivity 1W@m
93 dB
Max SPL
119 dB
HF
1x 0.75", 1" v.c. Neodymium
LF
1x 6.5", 1.5" v.c. Coaxial woofer
Dispersion
100x100°
X-Over Frequency
2100 Hz (internal X-Over)
Input Section
Connections
Screw terminal block (IN+ | IN- | OUT+ | OUT-)
Meccanica
Housing
Plywood, polyurea finish
Rigging points
2x M6 threaded nut
Accessories
bracket included
IP rating
IP 55
Width
195 mm (7.7 in)
Height
195 mm (7.7 in)
Depth
210 mm (8.3 in)
Weight
4.8 kg (10.6 lbs)
Notes: The data are not binding; dBTechnologies reserves the right to modify the data at any time and without previous notice.
**AES75: @1 meter, free field, with Music-Noise
