Der IS3T-TRF ist ein kompakter und robuster Passivlautsprecher für die hochwertige Wiedergabe von Hintergrundmusik. Dank des ABS-Gehäuses und der IP55-Zertifizierung ist der IS3T-TRF speziell für den Innen- und Außenbereich konzipiert. Er lässt sich dank seiner geringen Größe, der mitgelieferten Halterung und einem in Schwarz oder Weiß verfügbaren Finish leicht installieren und an jeden Kontext anpassen, wobei die Möglichkeit besteht, das Farbfinish der weißen Version selbst zu gestalten. Der IS3T-TRF ist als 2-Wege-Lautsprecher mit einem 3,5-Zoll-Tieftöner konfiguriert und eignet sich sowohl für traditionelle Impedanzsysteme als auch für 70/100-Volt-Technik, dank des Transformators.
Mehr erfahren
TECHNOLOGIES
White version availableThis product is available for purchase in black or white.
IP55 RatingThe product is resistant to dust and low-pressure water jets. Specifically, IP55 Rating offers limited protection against dust ingress and can withstand water jets from any direction without compromising functionality. This rating is commonly used for devices intended for both indoor and outdoor use.
Product code: 1030401370
Technische Daten
Speaker Type
Passive Speaker
Akustische Daten
RMS Power
30 W
Peak Power
120 W
Frequency Response [-6 dB]
110 hz - 19,000 Hz (custom preset)
Max SPL
107 dB
HF
1" exit, 0.5" v.c.
LF
1x 3.5", 1 v.c.
Dispersion
110° H x 100° V
Mechanik
Width
120 mm (4.7 inch.)
Height
190 mm (7.5 inch.)
Depth
118 mm (4.6 inch.)
Weight
1.6 kg (3.5 lbs.)
Housing
ABS
Accessories
bracket included
Notes: The data are not binding; dBTechnologies reserves the right to modify the data at any time and without previous notice.
Filename:
Category:
Filetype:
Size:
Language:
Release:
Manual_IS-TRF-series_Rev1.0
Manual
PDF
6,25 MB
English
2024-12-17
