IS25T-WP

Point Sources
Point Sources
152 mm 240 mm 485 mm

PASSIVE 2-WAY SPEAKER

MAX SPL 121.5 dB

FREQ RESPONSE [-6dB]: 85 Hz - 20,000 Hz

HF: 1x 1", 1.4" v.c.

LF: 2x 5", 1" v.c.

IP55 CERTIFIED

ROTATABLE HORN

WEIGHT: 7 kg (15.4 lbs)

Sales & Rental Network
L'IS25T-WP est une enceinte passive à 2 voies équipée de deux woofers de 5 pouces et d'un moteur à compression de 1 pouce pour les aigus. Cette enceinte offre une dispersion constante de 60x100° et constitue une solution robuste et performante pour la sonorisation en intérieur et en extérieur, grâce à ses points de fixation invisibles et à son indice de protection IP55. Le pavillon rotatif permet des installations verticales et horizontales avec des performances acoustiques élevées, en utilisant les mêmes accessoires dédiés que le système VIO X205. L'IS25T-WP conserve le design minimaliste de la série, avec la possibilité de personnaliser soi-même la finition de couleur de la version blanche.
En savoir plus

TECHNOLOGIES

EASE Focus
EASE FocusEASE Focus makes configuring a DVA or VIO system so much easier as this software simulates the system in the virtual realm. It can depict several audience target zones at the same time to map out more intricate venues including different coverage areas such as arenas, bleachers, and balconies. Color 2D graphics provide an easily understandable view of throw patterns and sound pressure levels so you can configure the array for the best possible results. It also offers you easy access to key rigging parameters such as the height of the rigging frame, the choice of pick points, the array’s bend, total weight, and system preset selections.
IP55 Rating
IP55 RatingThe product is resistant to dust and low-pressure water jets. Specifically, IP55 Rating offers limited protection against dust ingress and can withstand water jets from any direction without compromising functionality. This rating is commonly used for devices intended for both indoor and outdoor use.
Rotatable Horn
Rotatable HornSpecially designed, rotatable high-frequency horns provide very clean and constant directivity. By rotating the horn, the directivity of high frequencies can be adjusted, depending on the cabinet being assembled horizontally or vertically. A great and professional feature for fixed installation purposes or when a multifunctional speaker is used as stage monitor.
White version available
White version availableThis product is available for purchase in black or white.
Product code: 1030401240
Caractéristiques techniques
Speaker Type
Passive 2-way Speaker
Caractéristiques acoustiques
RMS Power
120 W
Peak Power
480 W
Frequency Response [-6 dB]
85 Hz - 20,000 Hz
Impedance
8 Ohm
Sensitivity 1W@m
94.5 dB
Max SPL
121.5 dB
HF
1x 1", 1.4" v.c.
LF
2x 5", 1" v.c.
Dispersion
100x60° [Rotatable Horn]
X-Over Frequency
1500 Hz (internal X-Over)
Input Section
Connections
Screw terminal block (IN+ | IN- | OUT+ | OUT-)
Mécanique
Housing
Plywood, polyurea finish
Rigging points
2x M10 threaded nut (top and bottom)
IP rating
IP 55
Width
152 mm (6 in)
Height
485 mm (19 in)
Depth
240 mm (9.4 in)
Weight
7 kg (15.4 lbs)
Notes: The data are not binding; dBTechnologies reserves the right to modify the data at any time and without previous notice.
AES75: @1 meter, free field, with Music-Noise
View All References
Filename: Category: Filetype: Size: Language: Release:
DWG_IS25T Drawing DWG 0,61 MB English 2021-05-19
Catalogue_Installation_2026 Catalogues PDF 7,36 MB English 2026-01-30
Catalogue_Installation-2025 Catalogues PDF 2,71 MB English 2025-05-29
CE_IS25T-WP Certifications PDF 1,65 MB English 2026-05-05
Quick-Start_IS25T-WP_Rev1.0 Manual PDF 0,77 MB English 2024-11-13
UKCA-IS25T-WP Certifications PDF 1,60 MB English 2026-05-05
GLL_IS25T_v1.0 GLL ZIP 4,64 MB English 2021-10-27
PRESET_dBTechnologies Presets ZIP 7,71 MB English 2026-02-19
Preset-Installer_IS-Series_1.3 Software ZIP 53,16 MB English 2025-06-10
PresetsInstaller_1.2_osx Software ZIP 19,68 MB English 2024-07-31
PresetsInstaller_1.2_win Software ZIP 19,69 MB English 2024-08-01
