VIO X206
VIO X206
After the success of VIO X205, which proved to be the perfect complement for VIO sound reinforcement systems, both in touring or fixed applications, dBTechnologies made the concept evolve designing VIO X206 which can easily serve as a powerful and sleek stand alone system.
After the success of VIO X205, which proved to be the perfect complement for VIO sound reinforcement systems, both in touring or fixed applications, dBTechnologies made the concept evolve designing VIO X206 which can easily serve as a powerful and sleek stand alone system.
VIO X206 is an ultra-compact professional speaker that delivers sound pressure and linear response to the highest level, just like VIO X205, but in addition to this, you can turn it into a true compact line array system. The speaker has been designed in two different versions, one model mounts a 90° by 60° rotatable horn. The other one is equipped with a two-path waveguide conveying a 100° by 15° dispersion, so perfect for line array applications. The real gem here is that users can remove and exchange horns at any time, based on their requirements.
The firmware to adapt the behaviour of the 2 horns can be changed accordingly with the quick switch on the back of the box.
VIO X206 is equipped with two 6.5" neodymium transducers and a 1" driver, powered by a 900W RMS Digipro G3 amp. Nevertheless, just like all companion cabinets in VIO X series, the cabinet allows for complete networkability thanks to RDNet and real time monitoring and control via Aurora Net.
Thanks to the two variants it cover a wide range of applications, meeting the requirements of both production and integration. This sleek, slim cabinet can easily fits onto a live stage, a corporate event facility, as well as a meeting room or a bar. A series of accessories helps you to create the best configuration for the venue. Several brackets adapt X206 on a speaker stand (VB-2X6, SA-2X6), one of them also allows it to be flown with a C clamp (VB-2X6). A simple link plate (LP-2) is available to pair or array them. It is also possible to use 2 of the 90x60° version both flown or ground stacked with a 60° spread bracket (LP-3). An extra 60° spread bracket allows for flying or polemounting of up to 6 90x60° boxes side by side, with a steady angle. A U shaped bracket (HB-2X6) allows for various configurations such as wall mounting or truss mounting. The same accessory also serves as horizontal pole mount for a 90x60° X206 or multiple line array versions of X206. If you need to stash a frontfill, or if you plan to ground stack several line arrays directly on a sub, this will be a safe and reliable solution to secure the load with the M20 threaded mount. Finally two flybars are available, a standard one for a single array (DRK-1) and a multiple one (DRK-2) that allows to fly 2 arrays of tops or subs, or even X206 and VIO S115 subs together.
Caractéristiques
  • Active 2-way speaker
  • 900 W RMS
  • LF 2x6.5” Neo - HF 1x1”
  • 90°x60° coverage version
  • Arrayable version with waveguide(100°x15°)
  • Maximum versatility in tour grade applications or fixed installations
/images/299/1848/70x70/nocrop/q-100/align-4/digipro%20G3.png
Digipro® G3
Système d'amplification numérique conçu par dBTechnologies. Le système est basé sur les versions précédentes Digipro mais a été complètement repensé. Les nouveaux composants et le nouveau dissipateur thermique décuplent les performances tout en réduisant la consommation.
/images/299/3731/70x70/nocrop/q-100/align-4/FIR-filters-icon.png
Linear Phase FIR Filters
A low-latency sound processing featuring Linear Phase FIR filters allows VIO cabinets to deliver an extremely coherent audio performance, standing out for its intelligibility and clarity from every listening position. This is also achieved by making the phase response as linear as possible, avoiding any distortion.
/images/299/5507/70x70/nocrop/q-100/align-4/Opto-isolated-icon.png
Opto-isolated preamp
The floating audio input design grants a digital optical isolation between earth ground from the mains and the audio ground flowing into the Preamplifier board.
This galvanic isolation greatly improves resistance to interferences and any unwanted buzzing and noises.
/images/299/816/70x70/nocrop/q-100/align-4/ICONES_RD_Net.png
RDNet
Digital net for bi-directional control of connected devices.
The acronym RDNet originates from the development, on behalf of RCF and dBTechnologies, of a universal network which allows adjustments in real time and supervision of all the connected systems, using cables based on ethernet cat 5 wires.
With the specific software and the interfaces control 2 and control 8, a complete command of the acoustic system will be possible allowing real time supervision on each electrical component of the various speakers.

RDNet allows you to
:
Monitor levels, limiters, and temperatures
Select system presets
Configure setups off-line
Mute units
Group modules and assigning group EQ, delay and phase
Test individual components
Automatically address system components
Tap into LAN and USB interfaces
Extend the network via wireless LAN access points.
/images/299/5509/70x70/nocrop/q-100/align-4/USB-icon.png
USB Data Port
Thanks to this universal data port, the user will be able to perform firmware upgrades
