IS25T-WP

IS25T-WP

Point Sources

Scarica immagini

Point Sources

PASSIVE 2-WAY SPEAKER

MAX SPL 121.5 dB

FREQUENCY RESPONSE [-6dB]: 85 Hz - 20,000 Hz

HF: 1x 1", 1.4" v.c.

LF: 2x 5", 1" v.c.

IP55 CERTIFIED

ROTATABLE HORN

WEIGHT: 7 kg (15.4 lbs)

Sales & Rental Network

IS25T-WP

IS25T-WP è il diffusore passivo a 2-vie dotato di due woofer da 5" e un driver a compressione da 1" per la gamma alta.

Questo cabinet fornisce una dispersione costante di 60x100°e rappresenta una soluzione resistente e performante per la sonorizzazione indoor e outdoor, grazie punti di montaggio invisibili e una certificazione IP55.

La tromba ruotabile consente installazioni verticali e orizzontali ad alta resa acustica, utilizzando gli stessi accessori dedicati al sistema VIO X205.

IS25T-WP conserva il design uniforme e minimale della serie, con la possibilità di personalizzare autonomamente la finitura cromatica della versione in bianco sulla base delle esigenze estetiche dell’installazione.

Scopri di più

TECNOLOGIE

EASE FocusEASE Focus makes configuring a DVA or VIO system so much easier as this software simulates the system in the virtual realm. It can depict several audience target zones at the same time to map out more intricate venues including different coverage areas such as arenas, bleachers, and balconies. Color 2D graphics provide an easily understandable view of throw patterns and sound pressure levels so you can configure the array for the best possible results. It also offers you easy access to key rigging parameters such as the height of the rigging frame, the choice of pick points, the array’s bend, total weight, and system preset selections.

Rotatable HornSpecially designed, rotatable high-frequency horns provide very clean and constant directivity. By rotating the horn, the directivity of high frequencies can be adjusted, depending on the cabinet being assembled horizontally or vertically. A great and professional feature for fixed installation purposes or when a multifunctional speaker is used as stage monitor.

White version availableThis product is available for purchase in black or white.

IP55 RatingThe product is resistant to dust and low-pressure water jets. Specifically, IP55 Rating offers limited protection against dust ingress and can withstand water jets from any direction without compromising functionality. This rating is commonly used for devices intended for both indoor and outdoor use.

Codice prodotto: 1030401240

Dati tecnici

Speaker Type

Passive 2-way Speaker

Dati acustici

RMS Power

120 W

Peak Power

480 W

Frequency Response [-6 dB]

85 Hz - 20,000 Hz

Impedance

8 Ohm

Sensitivity 1W@m

94.5 dB

Max SPL

121.5 dB

1x 1", 1.4" v.c.

2x 5", 1" v.c.

Dispersion

100x60° [Rotatable Horn]

X-Over Frequency

1500 Hz (internal X-Over)

Input Section

Connections

Screw terminal block (IN+ | IN- | OUT+ | OUT-)

Meccanica

Housing

Plywood, polyurea finish

Rigging points

2x M10 threaded nut (top and bottom)

IP rating

IP 55

Width

152 mm (6 in)

Height

485 mm (19 in)

Depth

240 mm (9.4 in)

Weight

7 kg (15.4 lbs)

Notes: The data are not binding; dBTechnologies reserves the right to modify the data at any time and without previous notice.
