IS4T-WP

Point Sources

Scarica immagini

Point Sources

PASSIVE FULLRANGE SPEAKER

MAX SPL 111 dB

FREQUENCY RESPONSE [-6dB]: 110 hz - 20,000 Hz

LF: 1x 4", 1 " v.c.

IP55 CERTIFIED

BRACKET INCLUDED

WEIGHT: 2 kg (4.4 lbs)

Sales & Rental Network

IS4T-WP

IS4T-WP è il più piccolo tra i diffusori dell’ampia serie IS per installazioni indoor e outdoor.

Dotato di un componente da 4", è un cabinet compatto ad alta versatilità, progettato essenzialmente per la musica di sottofondo.

Semplice e resistente, è una soluzione ottimale per la sonorizzazione indoor e outdoor attraverso un’installazione veloce garantita dalla staffa inclusa, punti di montaggio invisibili e una certificazione IP55. Ulteriore versatilità di connessione è supportata dai diversi accessori dedicati.

IS4T-WP conserva il design uniforme e minimale della serie, con la possibilità di personalizzare autonomamente la finitura cromatica della versione in bianco sulla base delle esigenze estetiche dell’installazione.

Scopri di più

TECNOLOGIE

EASE FocusEASE Focus makes configuring a DVA or VIO system so much easier as this software simulates the system in the virtual realm. It can depict several audience target zones at the same time to map out more intricate venues including different coverage areas such as arenas, bleachers, and balconies. Color 2D graphics provide an easily understandable view of throw patterns and sound pressure levels so you can configure the array for the best possible results. It also offers you easy access to key rigging parameters such as the height of the rigging frame, the choice of pick points, the array’s bend, total weight, and system preset selections.

White version availableThis product is available for purchase in black or white.

IP55 RatingThe product is resistant to dust and low-pressure water jets. Specifically, IP55 Rating offers limited protection against dust ingress and can withstand water jets from any direction without compromising functionality. This rating is commonly used for devices intended for both indoor and outdoor use.

Codice prodotto: 1030401210

Dati tecnici

Speaker Type

Passive Fullrange Speaker

Dati acustici

RMS Power

40 W

Peak Power

160 W

Frequency Response [-6 dB]

110 hz - 20,000 Hz

Impedance

8 Ohm

Sensitivity 1W@m

89 dB

Max SPL

111 dB

1x 4", 1 " v.c. Fullrange woofer

Dispersion

110x110°

Input Section

Connections

Screw terminal block (IN+ | IN- | OUT+ | OUT-)

Meccanica

Housing

Plywood, Polyurea finish

Rigging points

2x M6 threaded nut

Accessories

bracket included

IP rating

IP 55

Width

130 mm (5.1 in)

Height

130 mm (5.1 in)

Depth

150 mm (5.9 in)

Weight

2 kg (4.4 lbs)

Notes: The data are not binding; dBTechnologies reserves the right to modify the data at any time and without previous notice.

Nome file:	Categoria:	Tipologia:	Peso:	Lingua:	Rilascio:
DWG_IS4T	Drawing	DWG	0,82 MB	English	2021-05-19
Quick-Start_IS4T-WP-IS5T-WP-IS6T-WP_Rev1.0	Manual	PDF	0,64 MB	English	2024-11-13
GLL_IS4T_v1.0	GLL	ZIP	2,18 MB	English	2021-10-27
PresetsInstaller_1.2_osx	Software	ZIP	19,68 MB	English	2024-07-31
PresetsInstaller_1.2_win	Software	ZIP	19,69 MB	English	2024-08-01
