IS26T-WP

IS26T-WP

Point Sources

Scarica immagini

Point Sources

PASSIVE 2-WAY SPEAKER

MAX SPL 124 dB

FREQUENCY RESPONSE [-6dB]: 80 Hz - 20,000 Hz

HF: 1x 1", 1.7" v.c.

LF: 2x 6.5", 1.7" v.c.

IP55 CERTIFIED

ROTATABLE HORN

WEIGHT: 15.5 kg (34.17 lbs.)

Sales & Rental Network

IS26T-WP

IS26T-WP è il diffusore passivo full-range a 2-vie dotato di due woofer da 6,5” e un driver a compressione da 1" per la gamma alta.

Compatto, ad alta risposta lineare, IS26T-WP offre massima pressione sonora e condensa il meglio dell’esperienza acustica dBTechnologies nella soluzione più versatile dell’intera gamma IST-WP.

Il modello è caratterizzato da due diverse opzioni di copertura: una dispersione costante standard di 60x90° oppure un pattern di 100°x15°, che, grazie alla guida d’onda, trasforma facilmente IS26T-WP da point source a sistema line array.

Beneficiando di tutte le caratteristiche principali della serie, come i punti di montaggio invisibili e la certificazione IP55, questa soluzione passiva professionale sfrutta il concetto di massima versatilità consentendo decine di diverse configurazioni, realizzabili con gli accessori del sistema VIO X206.

IS26T-WP conserva il design uniforme e minimale dell’intera serie, con la possibilità di personalizzare autonomamente la finitura cromatica della versione in bianco sulla base delle esigenze estetiche dell’installazione.

Scopri di più

TECNOLOGIE

EASE FocusEASE Focus makes configuring a DVA or VIO system so much easier as this software simulates the system in the virtual realm. It can depict several audience target zones at the same time to map out more intricate venues including different coverage areas such as arenas, bleachers, and balconies. Color 2D graphics provide an easily understandable view of throw patterns and sound pressure levels so you can configure the array for the best possible results. It also offers you easy access to key rigging parameters such as the height of the rigging frame, the choice of pick points, the array’s bend, total weight, and system preset selections.

Rotatable HornSpecially designed, rotatable high-frequency horns provide very clean and constant directivity. By rotating the horn, the directivity of high frequencies can be adjusted, depending on the cabinet being assembled horizontally or vertically. A great and professional feature for fixed installation purposes or when a multifunctional speaker is used as stage monitor.

White version availableThis product is available for purchase in black or white.

Codice prodotto: 1030401250

Dati tecnici

Speaker Type

Passive 2-way Speaker

Dati acustici

RMS Power

250 W

Peak Power

1000 W

Frequency Response [-6 dB]

80 Hz - 20,000 Hz

Impedance

8 Ohm

Sensitivity 1W@m

94 dB

Max SPL

124 dB

1x 1", 1.7" v.c.

2x 6.5", 1.7" v.c.

IS26T Dispersion

60x90° [rotatable horn]

IS26T100 Dispersion

100x15° [H x V]

X-Over Frequency

1200 Hz (internal X-Over)

Input Section

Connections

Screw terminal block (IN+ | IN- | OUT+ | OUT-)

Meccanica

Housing

Plywood, polyurea finish

Rigging points

2x M10 threaded nut (top and bottom)

IP rating

IP 55

Width

210 mm (8.3 in)

Height

650 mm (25.6 in)

Depth

270 mm (10.6 in)

Weight

15.5 kg (34.17 lbs)

Notes: The data are not binding; dBTechnologies reserves the right to modify the data at any time and without previous notice.
