FLEXSYS FM12

Stage Monitors
Torna alla galleria
Stage Monitors
Con una potenza di 600 W, FM12 è un sistema coassiale con 8 memorie di equalizzazione per meglio adattarsi a tutti gli utilizzi anche come piccolo PA installato su piantana.

Il woofer da 12” permette uno spettro sonoro veramente completo.

La configurazione coassiale e la costruzione in multistrato di betulla con fianchi in polipropilene lo rendono acusticamente perfetto ed al contempo pratico e leggero
Scopri di più

TECNOLOGIE

Coaxial Speaker
Coaxial SpeakerThese coaxial speakers deliver an extraordinary sound quality that defies the compact design of their housings. Engineered for precise directivity and uniform throw patterns, they provide the same satisfying audio experience from every listening position, with far greater resistance to Feedback.
Low Profile Monitor
Low Profile MonitorThe use of diffusion monitors is normally tied to stages for every kind of musical event. A monitor with a low profile design allows the stage to be more vacant on sight, optimizing space on stage in a rational way and allowing a more pleasant vision.
Multifunctional Housing
Multifunctional HousingA multifunctional housing offers many placement options, for instance as a floor monitor, satellite speaker in combination with subwoofers or as a fullrange system on pole mounts.
Preset System
Preset SystemThe opportunity of modifying the character and equalization of a speaker is a very important prerogative in adapting a speaker to multiple functions. The introduction of the Preset System enables to choose directly from the box the most adeguate equalization for the desired use, optimizing performances without the need of external processors. The management of phase, limiter and x-over will be modified automatically depending on the chosen set-up, preserving the internal acoustic equipment.
Dati tecnici
Speaker Type
2-Way Active Coaxial Stage Monitor

Dati acustici
Frequency Response [+/- 3dB]
67 - 20.000 Hz

Max SPL
126 dB

HF
1 "

Type HF
compression driver

Horn
CD Horn

LF
12"

Amplificatore
Amp Technology
Digipack™

Amp Class
Class D

Power PRG
600 W

Peak Power
1200 W

Processore
Controller
DSP 24bit/48kHz

System Presets
8 presets

Limiter
Dual Active

Peak, RMS, Thermal

Meccanica
Housing
Multiplex with H.E.T coating, reinforced

Housing Design
Multifunctional, Low Profile

Angles Up
2 monitor angles °

Width
490 mm (19.3 in)

Height
290 mm (11.41 in)

Depth
410 mm (16.14 in)

Weight
17 kg (37.48 lbs)

Notes: The data are not binding; dBTechnologies reserves the right to modify the data at any time and without previous notice.
Nome file: Categoria: Tipologia: Peso: Lingua: Rilascio:
DWG_Flexsys-FM-12 Drawing DWG 1,66 MB English 2015-07-29
Flexsys Monitor-MAN Rev2.0 Manual PDF 5,23 MB English 2016-01-13
