Multifunctional HousingA multifunctional housing offers many placement options, for instance as a floor monitor, satellite speaker in combination with subwoofers or as a fullrange system on pole mounts.
Neodymium TransducersNeodymium is a metal belonging to the family of the “rare earth”, a particular material which creates a powerful magnetic field once charged. This material, used in acoustic transducers, possesses a far superior magnetic power compared to the classical ferrite which allows its dimensions to be reduced, favoring its weight and space capacity.
Technical Data
Speaker Type
2-Way Active Speaker
Acoustical data
Frequency Response [-10dB]
70 - 20.000 Hz
Max SPL
118 dB
HF
1 "
Type HF
Neodymium driver
Directivity
80 x 60 °
LF
2x 6.5“
Type LF
Neodymium
Amplifier
Amp Technology
digipro®
Amp Class
Class D
Power PRG
300 W
Cooling
Convection
Processor
Controller
DSP 24bit/48kHz
Limiter
Dual Active Peak, RMS, Thermal
Input
Signal Input
1x XLR
1x 6.3mm phone jack
1x RCA cinch
Microphone Input
YES
Signal Output
1x XLR
1x 6.3mm phone jack
1x RCA cinch
Power Socket
VDE
Voltage Range
240 V
Mechanics
Housing
Polyporpylen PP
Pole Mount
Optional
Rigging Points
4x M5
Width
210 mm (8.4 in)
Height
350 mm (14 in)
Depth
270 mm (10.8 in)
Weight
5.5 kg (12.13 lbs)
Notes: The data are not binding; dBTechnologies reserves the right to modify the data at any time and without previous notice.
